Lenze E94AMHE0034 Inverter | 9400 series, 2.5A, 0.75kW

Product Overview

The Lenze E94AMHE0034 inverter is a high-precision servo drive from the Lenze 9400 series HighLine range, designed for accurate, efficient motor control in industrial automation. As a Multi Drive version, the Lenze E94AMHE0034 inverter runs from a 565VDC rated bus voltage, so it fits multi-axis machines where several drives share one common DC link.

With a rated output current of 2.5A and a typical motor power of 0.75kW, the Lenze E94AMHE0034 inverter suits small to medium servo motors. It operates at an 8kHz switching frequency for smooth, responsive speed and torque regulation, and it handles dynamic load changes during acceleration and fast motion changes without losing stability. This consistent control improves machine accuracy, reduces mechanical wear, and helps lower maintenance costs over the equipment’s lifetime.

The compact design weighs approximately 3.2kg and is made for panel installation, so it integrates easily into control cabinets. Its IP20 protection rating guards against accidental contact with internal components. It works in ambient temperatures from 0°C to 40°C, can be stored from -25°C to 70°C, and tolerates 5% to 95% non-condensing relative humidity, which covers typical industrial conditions without special climate control. For automation builders looking for a dependable 9400 series drive, the Lenze E94AMHE0034 inverter combines precision, reliability, and energy efficiency in a small package.

Key Features

• Lenze 9400 Series HighLine Drive: Intelligent, simple servo system platform
• Multi Drive Design: Shared DC-bus operation at 565VDC for multi-axis systems
• 2.5A Rated Output Current: Suited to compact servo motors
• 0.75kW Typical Motor Power: Efficient control for small to medium axes
• 8kHz Switching Frequency: Smooth, accurate speed and torque regulation
• Handles Dynamic Loads: Stable performance during acceleration and fast motion changes
• Compact Panel Mounting: Lightweight at approximately 3.2kg
• IP20 Protection: Safe operation in controlled industrial environments
• Wide Environmental Tolerance: 0°C to 40°C operation, 5% to 95% humidity (non-condensing)

Applications

The Lenze E94AMHE0034 inverter suits a wide range of servo-driven processes:

• Conveyor Systems: Accurate, adjustable-speed axis control
• Packaging Equipment: Synchronized, responsive motion for packaging lines
• Robotics: Precise servo control in automated cells
• Multi-Axis Machines: Compact axis module for shared DC-bus systems
• General Automated Machinery: Servo-driven processes needing consistent output quality
